When your welding job won’t wait and you’re close to other workers, help protect them with the Wilson Orange See-Thru Welding Curtain. The heavy-duty 14-mil vinyl welding screen is designed to filter far and near ultraviolet (UV) radiation and blue light. They come with ready-to-hang grommets (framing and tubing sold separately) and are a smart item on your list of welding supplies.
The heavy-duty orange vinyl is designed to filter far / near UV radiation and blue light
Grommeted and ready to hang (tubing or framing is not included); Plastic grommets are placed 8” apart on one width side and 16” apart on both height sides
These welding screens help protect bystanders from ultraviolet light while welding is being performed; not intended for use in lieu of visors, goggles, eyewear or welding helmets
WILSON Welding Curtains meet or exceed California State Fire Marshall (CFM) requirements for flame resistance
